Wakeboard boats (usually just called wake boats) are inboard boats built to throw a big, clean wake on purpose. A deep hull, a rear-mounted V-drive engine, and tanks that pump in thousands of pounds of water ballast let it push more water than an ordinary runabout, so riders get a ramp-like wake for wakeboarding or a rideable wave for wake surfing. Most also have a tower for a high tow point and a surf system that shapes the wave to one side.

Table of Contents
Key Takeaways
| Topic | Key takeaway |
|---|---|
| What it is | An inboard boat built to throw a big, clean wake for wakeboarding and wake surfing |
| How it works | Deep hull, rear V-drive engine, water ballast and wake-shaping surf systems |
| Riding speeds | About 18 to 24 mph for wakeboarding, 10 to 13 mph for wake surfing |
| Cost | Roughly $75,000 to $300,000+ new; used boats cost far less |
| Worth it? | Yes for frequent riders; a pontoon or bowrider is cheaper for cruising and fishing |
How a Wake Boat Makes Its Wake
Every boat leaves a wake. A wake boat is designed so that wake is as big, steep and predictable as possible. Five design choices do most of the work.
1. A deep, heavy hull
Wake boat hulls sit deeper in the water than ski boat hulls. Displacing more water at the stern is what builds a tall wake. Ski boats do the opposite, using a shallower hull to cut drag and keep the wake flat.
2. A V-drive engine at the back
In a V-drive, the engine sits at the stern facing backward and the drive shaft runs forward and down to the prop under the hull. That puts the engine’s weight where it deepens the wake and frees up the middle of the boat for seating. Ski boats usually use a direct drive with the engine in the center.
3. Water ballast
Built-in tanks fill with lake water at the push of a button. Current models carry anywhere from about 1,500 to 5,000 pounds, and premium boats can fill in a few minutes. More weight means a bigger wake, and filling one side more than the other tilts the boat to set up a surf wave. Older boats often relied on add-on ballast bags. Our guide to how much a boat weighs puts those numbers in context.
4. Wake shapers and surf systems
Movable plates or tabs at the transom redirect water to clean up one side of the wake for surfing. Each brand has its own version, such as Malibu Surf Gate, the Nautique Surf System, MasterCraft’s surf system, Supra Swell and Tigé TAPS. Some boats add a hydrofoil under the hull that pulls the stern down instead of relying only on ballast.
5. A wakeboard tower
The tower raises the tow point several feet above the deck. A higher pull point gives wakeboarders more lift off the wake and less downward tug on the rope. Towers also hold board racks, speakers and a bimini top.

Wake Boat vs. Ski Boat
Both are inboard tow boats, which is why they get confused. They are built for opposite goals: a ski boat wants the smallest wake possible, and a wake boat wants the biggest. If you’re weighing a different kind of boat altogether, see our comparison of a pontoon boat or ski boat.
| Wake boat | Ski boat | |
|---|---|---|
| Wake | Large, steep, adjustable | Small and flat |
| Drive | V-drive, engine at the stern | Usually direct drive, engine in the middle |
| Hull | Deep, displaces more water | Shallow, low drag |
| Ballast | Built-in tanks, often thousands of pounds | Little or none |
| Seating | Larger bow and stern lounges | Smaller cockpit |
| Best for | Wakeboarding, wake surfing, family days on the lake | Water skiing, slalom |
Wakeboarding vs. Wake Surfing Behind a Wake Boat

The same boat handles both sports, but it’s set up differently for each.
- Wakeboarding: the rider holds a tow rope and uses the wake as a ramp for jumps and tricks. Boat speed is usually about 18 to 24 mph, slower for beginners and faster for experienced riders.
- Wake surfing: the rider starts on a rope, then drops it and rides the wave a few feet behind the boat. Speed drops to about 10 to 13 mph, and ballast is loaded heavier on the surf side.
Why only inboards for surfing: a wake surfer rides very close to the stern. On an inboard, the prop is tucked under the hull, well forward of the rider. Traditional outboards and sterndrives put the prop at the back of the boat, right where a surfer would fall, so you shouldn’t wake surf behind them. A few newer sterndrive boats use forward-facing props built for surfing. Carbon monoxide from the exhaust also collects near the stern at low speeds, which is another reason to keep riders off the back of the boat while the engine runs.
Popular Wake Boat Brands and Price Ranges
New wake boats are expensive, and options like bigger engines, upgraded surf systems and premium audio can add tens of thousands to the base price. These ranges are approximate starting points; dealer pricing and options vary.
| Tier | Example brands and models | Approximate new price |
|---|---|---|
| Entry | Heyday WT-1, Moomba Mondo, Axis A20 | $75,000 to $110,000 |
| Mid-range | Axis A22 and A24, Moomba Max, MasterCraft NXT, Supra SA, Malibu 23 LSV | $110,000 to $175,000 |
| Premium | MasterCraft X series, Malibu 25 LSV, Nautique G23, Tigé RZX, Centurion Ri245 | $175,000 to $275,000 |
| Flagship | Nautique Paragon, Malibu M240, MasterCraft XStar, Centurion Ri265 | $275,000 and up |
A few well-known models:
- MasterCraft XStar: MasterCraft’s flagship, built around a large wake and surf wave.
- Malibu Wakesetter 25 LSV: a big, high-capacity boat with Malibu’s Surf Gate and Power Wedge hydrofoil.
- Nautique G23: a premium 23-footer known for its wakeboard wake and surf wave.
- Axis A20: one of the most affordable ways to get a true V-drive wake boat.
New vs. Used Wake Boats
Because new prices are so high, many people start used. Premium brands hold value well; a five-year-old MasterCraft or Nautique often keeps around two-thirds to three-quarters of its original price. Older boats that are 15 or more years old can cost a fraction of that, but they usually have smaller ballast systems, no modern surf system and more engine hours.
When shopping used, check:
- Engine hours and service records. Wake boats spend a lot of time at low speed with heavy ballast, which is hard on engines.
- Ballast pumps and tanks. Run every pump and look for leaks or mold in the bags or tanks.
- The surf system. Make sure the plates or tabs move on both sides and the controls work.
- The trailer. A loaded wake boat is heavy, so check tires, brakes and bearings, and confirm your tow vehicle can handle it.
Is a Wake Boat Worth It?
It’s worth it if your household wakeboards or wake surfs often, you boat on a lake big enough for it, and you want a boat that also works as a comfortable day cruiser.
It may not be if you mostly fish, cruise or tube. A pontoon or bowrider costs far less to buy, fuel and insure. Wake boats also burn more fuel than lighter boats, especially with full ballast, and some lakes now limit where large wakes are allowed to protect shorelines and docks, so check local rules first.
If you want to try the sport before buying, a boat club is a cheaper way to spend a season behind a wake boat.

Frequently Asked Questions
Can you wakeboard behind a regular boat?
Yes. Any boat that can reach about 18 mph can pull a wakeboarder, including bowriders and many pontoons. The wake will just be smaller and softer, which is fine for learning. You can even wakeboard behind a jet ski. What you shouldn’t do is wake surf behind a boat with an outboard or traditional sterndrive.
Do wakeboard boats have propellers?
Yes. The prop sits under the hull, forward of the stern, and a rudder behind it steers the boat. That placement keeps it away from riders behind the boat.
How much ballast does a wake boat hold?
Most current wake boats carry roughly 1,500 to 5,000 pounds of water ballast, depending on size and brand. Many owners add ballast bags for an even bigger wave.
How fast should a boat go for wakeboarding?
About 18 to 24 mph for wakeboarding and about 10 to 13 mph for wake surfing. Beginners should start at the low end.
What’s the difference between a wake boat and a surf boat?
Today they are usually the same boat. Most new wake boats come with a surf system and are marketed for both wakeboarding and wake surfing.
Final Thoughts
A wake boat is a specialized, expensive tool, and it shines when your family rides often. If you mainly cruise, fish or tube, a simpler boat costs far less to own. If you do buy, a well-kept used boat from a premium brand is often the best value.
Resources
- Boat manufacturer specifications (MasterCraft, Malibu, Nautique, Axis, Supra)
- Water Sports Industry Association: wake surfing safety guidance
- U.S. Coast Guard: carbon monoxide and boating safety
